Powerfoil® X3.0 size 12ft (sải cánh 3.6m) là dòng quạt trần công nghiệp lớn nhất, mạnh nhất của hãng Big Ass Fans USA. Và đặc điểm nổi bật của nó là sử dụng động cơ NitroSeal Gearbox sử dụng khí Nito thay vì dùng dầu bôi trơn và công nghệ bánh răng HeliCambe giúp cho động cơ hoạt động vĩnh viễn mà không cần bảo dưỡng. Thời gian bảo hành lên đến 15 năm
Powerfoil X3.0 có bộ cánh quạt (aerofoils) và winglets được thiết kế theo không gian được cấp bằng sáng chế có hiệu suất luồng gió mạnh và đồng bộ
Bộ điều khiển (Wall control) nhỏ gọn, tích hợp rờle cảnh báo cháy trong PCCC
Thiết kế Big Ass Fans và lắp ráp 100% tại Hoa Kỳ
Reference:
PFX3-12
Brand:
Love0
Add to compare0
Add to wishlist
Thông số kỹ thuật Powerfoil X3.0 Series
Model | Sải cánh (feet) | Trọng lượng | Tốc độ (RPM) | Nguồn điện | Công suất động cơ | Ống ty treo nối dài |
PFX3-12 | 12 ft (3.6 m) | 245 lb (111 kg) | 139 RPM | 200–240 VAC, 50/60 Hz, 1 Φ, 30 A 380–480 VAC, 50/60 Hz, 3 Φ, 10 A |
1.5 Hp 1.1kW |
4ft (1,2m) |
PFX3-14 | 14 ft (4.3 m) | 254 lb (115 kg) | 118 RPM | |||
PFX3-16 | 16 ft (4.9 m) | 264 lb (120 kg) | 99 RPM | 2.0Hp 1.5kW |
||
PFX3-18 | 18 ft (5.5 m) | 281 lb (127 kg) | 88 RPM | |||
PFX3-20 | 20 ft (6.1 m) | 290 lb (132 kg) | 78 RPM | |||
PFX3-24 | 24 ft (7.3 m) | 347 lb (157 kg) | 65 RPM |
PFX3-12
Data sheet
- Mounting
- Controller
- Standard Controller
- Winglets
- Winglet Yellow
- Airfoils material
- Aluminum - Nhôm với thiết kế loại bỏ tiếng ồn
- Consumption Power
- 1.5 HP (1.1kW)
2.0 HP (1.5kW)
- Model (SKU):
- PFX
- Power-Input
- 200–240 VAC, 1 Φ, 50/60 Hz
380–480 VAC, 50/60 Hz, 3 Φ, 10 A
- Operating temperature
- 0° to 40° C
- System integration
- BACnet
Building automation systems (quản lý tòa nhà thông minh)
Fire suppression system - Hệ thống cảnh báo PCCC
Modbus-RTU
- Environmental standards
- IP55
- Optional
- BACnet adapter)
BAFCon™ Controller
BMS (0–10 VDC
Bộ đèn LED công nghiệp
Modbus Standard
SmartSense Controller
- Spec Motor
- NitroSeal Gearbox motor
