Powerfoil® 8 sải cánh 18ft (~ 5.5m) là một chiếc quạt trần đáp ứng khả năng trong ngành công nghiệp nặng mang đến sự thoáng mát đặc biệt và tiết kiệm năng lượng quanh năm.
Bộ cánh sản xuất tại Malaysia
Biến tần + Motor sản xuất tại USA
Reference:
PF8-18
Brand:
Love0
Add to compare0
Add to wishlist
Thông số kỹ thuật Powerfoil 8 Series
Model | Sải cánh (feet) | Trọng lượng | Tốc độ (RPM) | Nguồn điện | Công suất động cơ | Ống ty treo nối dài |
PF8-12 | 12 ft (3.6 m) | 200 lb (91 kg) | 135 RPM | 200–240 VAC, 50/60 Hz, 1 Φ, 25 A 380–480 VAC, 50/60 Hz, 3 Φ, 10 A |
1.5 Hp 1.1kW |
4ft (1,2m) |
PF8-14 | 14 ft (4.3 m) | 209 lb (95 kg) | 109 RPM | |||
PF8-16 | 16 ft (4.9 m) | 224 lb (102 kg) | 98 RPM | 2.0Hp 1.5kW |
||
PF8-18 | 18 ft (5.5 m) | 233 lb (106 kg) | 86 RPM | |||
PF8-20 | 20 ft (6.1 m) | 242 lb (110 kg) | 76 RPM | |||
PF8-24 | 24 ft (7.3 m) | 261 lb (118 kg) | 60 RPM |
PF8-18
Data sheet
- Mounting
- I-Beam, Z-Pulins
- Controller
- Standard Controller
- Winglets
- Winglet Yellow
- Airfoils material
- Aluminum - Nhôm với thiết kế loại bỏ tiếng ồn
- Consumption Power
- 1.5 HP (1.1kW)
2.0 HP (1.5kW)
- Color
- Silver/Yellow
- Model (SKU):
- PF8
- Power-Input
- 200–240 VAC, 1 Φ, 50/60 Hz
380–480 VAC, 50/60 Hz, 3 Φ, 10 A
- Operating temperature
- 0° to 40° C
- System integration
- BACnet
Building automation systems (quản lý tòa nhà thông minh)
Fire suppression system - Hệ thống cảnh báo PCCC
Modbus-RTU
- Environmental standards
- IP54
- Optional
- BACnet adapter)
BAFCon™ Controller
BMS (0–10 VDC
Modbus Standard
SmartSense Controller
- Noise (dBA)
- 55 dBA
- Spec Motor
- AC Gearbox motor
